"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump

China "L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump supplier
"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump supplier "L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump supplier "L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump supplier "L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump supplier "L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump supplier "L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump supplier "L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump supplier "L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump supplier "L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump supplier "L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump supplier

Large Image :  "L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump

Product Details:

Place of Origin: CHINA
Brand Name: SOUTHWEST, OILWELL, GARDNER DENVERNATIONAL, EMSCO, DRILLMEC, GARDNER DENVER
Certification: API 7K
Model Number: FB1600

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: 1 to 500 usd
Packaging Details: Suitable to shipment by sea and air
Delivery Time: In stock
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 3000 pieces per month
Contact Now
Detailed Product Description
Usage: Oil,Water,drill Rig Power: Electric,Hydraulic,diesel
Pressure: High Pressure,Low Pressure Application: Mining,oil,Chemical
Structure: Piston Pump,Single-stage Pump Fuel: Diesel,Electric
Standard Or Nonstandard: Standard Theory: Centrifugal Pump,Reciprocating Pump,Diaphragm Pump
Type: Mud Pump Weight: 100-3700kg
Color: Blue,red And So On,Green Or Per Customer Design Material: Cast Iron/stainless Steel Mud Suction Pump,Chrome Alloy
Warranty: 12 Months Feature: Compact Size
Product Name: Mud Pump Head: 10m Mud Suction Pump
Oem: Can Be Accept,Applicable Inlet Pipe (mm)/(in): DN200 / 8
Condition: New

"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump

FB1300/1600 Mud Pump

"L" MODULE FOR EMSCO FB-1300, FB-1600 QTY PER PUMP
FLUID END MODULE & ACCESSORIES
ITEM # OEM PART # MISSION PART # DESCRIPTION
    FEMFB13ASSYSW FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS: 1 - 27) 3
1 8490-1D FEMFB13DISSW MODULE, DISCHARGE STUDDED (INCLUDES ITEMS:1, 3-11) 3
2 8490-2S FEMFB13SUCSW MODULE, SUCTION STUDDED (INCLUDES ITEMS: 2, 5, 6, & 27) 3
3 4016-97 OWA17DSUCSSW STUD, DISCHARGE TO SUCTION MODULE 18
4   EMSF1000PFSN NUT, DISCHARGE TO SUCTION STUD 18
5 4015-2 OWA17TRSSW STUD, THREADED RING 72
6   PZ789GPFSN NUT, THREADED RING STUD 72
7 4016-9 EMSFB13PFSSW STUD, POWER FRAME 18
8   EMSF1000PFSN NUT, POWER FRAME STUD 18
9 4017-36 PEP80 CAPSCREW, LINER RETAINER FLANGE (SOCKET HEAD) 24
10 4017-46 FB1300DMSSW STUD, DISCHARGE MANIFOLD 12
11   IDT800TRSN NUT, DISCHARGE MANIFOLD STUD 12
12 8488-5 PEP70 PIN, DOWELL 6
13 2988 1290344 SEAL, SUC TO DISCH MOD & WEAR PLATE - RUBBER (SEE DATASHEET FOR ALT MATLS) 6
14 8422-3 EMSF1000ARSW RING, LINER RETAINER PILOT 3
15 8490-3 EMSFB13WPSW PLATE, LINER WEAR 3
16 6490-3 EMSFB13LRPSW FLANGE, LINER RETAINER 3
17 6590-1 EMSFB13LLSW NUT, LINER LOCK 3
18 P-129 07207129 GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6
19 4016-99 PEP73 CAPSCREW, VALVE GUIDE 12
20 4700-I PZ789VGI BUSHING, VALVE GUIDE 6
21 4775-2R EMSFB13VGASW GUIDE, VALVE (INCLUDES ITEMS 20, 21) 6
22 4675-2A EMSFB13VCASW PLUG, VALVE COVER (INCLUDES ITEMS 19-22) 6
23 4475 OWA17FLGSW RING, THREADED 6
24 4575 OWA17CAPSW CAP, THREADED 6
25 568-343 99609343 GASKET, DISCHARGE MANIFOLD 3
26 568-442 99609442 GASKET, SUCTION MANIFOLD 3
27 4018-19 700048511 CAPSCREW, SUCTION MANIFOLD 18


"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump

All our fluid end parts are manufactured to API 7K quality standards.

Parts are available for these popular pump models:

BOMCO/Emsco Mud Pumps:F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,

LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600
Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,
National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,
Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,

Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT

Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200

Russian Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32

WEATHERFORD/Ellis Williams: E-447, E-2200

Drillmec: 9T1000, 12T1600, 7TS600, 7TS500, 9T800

Romania: 3PN-1000, 3PN-1600, 3PN-2000

And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.

"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump
"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump
"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump





OEM Style Modules Mission L Modules
Brewster B-1000-T/B-1100-T Mission L Brewster B-1300-T/B-1600-T
Brewster B-1300-T/B-1600-T Mission L Emsco F-800, F-1000
Ellis Williams 9-W-1000 Mission L Emsco FB-1300/FB-1600
Emsco F-350/F-500/F-650 Mission L Gardner Denver PZ-7
Emsco F-800/F-1000 Mission L Gardner Denver PZ-8
Emsco FB-1300/FB-1600 Mission L Gardner Denver PZ-9
Emsco FC-1600 Mission L Gardner Denver PZ-10/PZ-11
Emsco FC-2200 Mission L Ideco T-1300/T-1600
Gardner Denver PAH Mission L National 9-P-100
Gardner Denver TEE Mission L National 10-P-130
Gardner Denver PX-11(2000 HP) 7500 psi Mission L National 12-P-160
Gardner Denver PZ-7/PZ-8/PZ-9 Mission L National 12-P-160 "New Style"
Gardner Denver PZ-7/PZ-8/PZ-9 w/ Wear Plate Mission L Oilwell A-850-PT/A-1100-PT
Gardner Denver PZ-10/PZ-11 Mission L Oilwell A-1400-PT/A-1700-PT
Gardner Denver PZ-10/PZ-11 w/ Wear Plate Mission L Wirth TPK-1300/TPK-1600
Ideco T-500
Ideco T-800/T-1000
Ideco T-1300/T-1600 Mission "L" 7500 PSI Asemblies
National 7-P-50 Mission L National 12-P-160 (7500 PSI Working Pressure)
National 8-P-80 Tapr-Lok Mission L National 14-P-220 (7500 PSI Working Pressure)
National 8-P-80 Fast Change Mission L Oilwell A/HD-1700-PT 7500 PSI Working Pressure
National 9-P-100 Tapr-Lok
National 9-P-100 Fast Change
National 10-P-130 Tapr-Lok
National 10-P-130 Fast Change
National 12-P-160 Tapr-Lok
National 12-P-160 Fast Change
National 12-P-160 7500 PSI
National 14-P-220
Oilwell A-850/1100/1400/1700-PT

"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump



National Oil well Varco (NOV) is an American multinational corporation based in Greater Sharps town, Houston, Texas. It is a leading worldwide provider of equipment and components used in oil and gas drilling and production operations, oilfield services, and supply chain integration services to the upstream oil and gas industry. The company conducts operations in more than 1,200 locations across six continents.
Products include all the heavy hardware for oil well drilling as well as drilling instrumentation and controls and drilling power generation and control. A partial list of heavy hardware includes top drives, rotary, draw works, derricks, BOPs (blowout preventers), mud pumps, riser equipment, and complete drilling rigs. Products also include instruments and controls required on the rig floor for the drilling operation. This includes sophisticated electronics for precise control, such as the control system Cyber base. NOV also produces control electronics for power generation and control of drilling motors and motor control centers for AC motor control.
NOV is the Houston area’s largest energy employer, with more than 14,500 workers in the region



"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump



MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE) QTY PER PUMP
FLUID END MODULE & ACCESSORIES (INCLUDING DISCHARGE MANIFOLD)
ITEM # MISSION PART # DESCRIPTION
  80704032 FLUID END ASSEMBLY COMPLETE INCLUDES ITEMS (1-27) ENOUGH FOR 1 PUMP 1
1 80704000 MODULE, DISCHARGE STUDDED (INCLUDES ITEMS 1,9,10,13,14,18,19,20,& 27) 3
2 80704001 MODULE, SUCTION STUDDED (INCLUDES ITEMS 2,3,4,18,&19) 3
3 80704002 STUD, (DISCHARGE TO SUCTION MODULE) 24
4 PEP55 NUT, HEAVY HEX 24
5 80704003 THREADED RING 6
6 80704004 THREADED CAP 6
7 80704005 VALVE COVER (INCLUDES 11,12,& 17) 6
8 80704006 DISCHARGE MANIFOLD (7500 PSI WORKING PRESSURE) 1
9 80702011 STUD, DISCHARGE MANIFOLD 12
10 IDT800TRSN NUT,HEX HEAVY 12
11 PZ789VGI BUSHING, VALVE GUIDE 6
12 12PVGASW GUIDE, VALVE 6
13 8P80TRSN NUT, POWER FRAME STUD 30
14 PEP75 CAPSCREW, LINER RETAINER 18
15 12PLASW RETAINER, LINER FLANGE 3
16 12PLANSW NUT, LINER RETAINER 3
17 7007303 SCREW, VALVE GUIDE 12
18 6300240 NUT, HEAVY HEX FOR THREADED RING 72
19 80700014 STUD, THREADED RING 72
20 PEP70 PIN, DOWELL 6
21 1290344 SEAL, DISCH TO SUC & WEARPLATE - RUBBER (SEE DATASHEET FOR ALT MATLS) 6
22 07207129 SEAL, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 3
23 99609235 SEAL, DISCHARGE MANIFOLD 3
24 1540851 SEAL, SUCTION MANIFOLD 3
25 700048511 CAPSCREW, SUCTION MANIFOLD 3
26 PP6021260SW WEARPLATE 3
27 NAT12P160PFS STUD, POWER FRAME 30



"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump



MISSION "L" MODULE FOR BOMCO F1600 7500 PSI SWOP VERSION QTY PER PUMP
FLUID END MODULE & ACCESSORIES
ITEM # SW PART # MISSION PART # DESCRIPTION
  8404-25A   FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS) 3
1 8404-26   MODULE, SUCTION STUDDED (INCLUDES ITEMS 1, 7-8) 3
2 8404-27   MODULE, DISCHARGE STUDDED (INCLUDES ITEMS 2-9) 3
3 4019-61   STUD, DISCHARGE TO SUCTION MODULE 18
4 1-3/4-8 HH 6300281 NUT, DISCHARGE TO SUCTION STUD 18
5 4017-33   STUD, POWER END 30
6 1-1/2-8 HH 0-7601-0630-28 NUT, POWER END STUD 30
7 Feb-15 OWA17TRSSW STUD, THREADED RING 72
8 1-1/4-7 HH 6300200 NUT, THREADED RING STUD 72
9 8488/5/1- 6511416 PIN, DOWELL 6
10 4019-51 7006444 CAPSCREW, LINER RETAINER FLANGE 3/4-10X3 18
11 8490-28   PLATE, LINER WEAR 3
12 2988 1290344 GASKET, WEAR PLATE AND MODULE - RUBBER (SEE DATASHEET FOR ALT MATLS) 6
13 568-443 99609443 O-RING, WEAR PLATE 3
14 6490-25   FLANGE, LINER RETAINER (LINER BUSHING) 3
15 6590-25   NUT, LINER RETAINER 3
16 4690-25A   ASSY, VALVE COVER PLUG (INCLUDES ITEMS 15,16, 20-22) 6
17     PLUG, VALVE COVER 6
18 4488-25   RING, THREADED (THREADED FLANGE) 6
19 4588-25   CAP, THREADED (SCREW GLAND) 6
20 P-115 7207115 SEAL, VALVE COVER PLUG - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6
21 4788R-25   ASSEMBLY, VALVE GUIDE (INCLUDES ITEMS 20 & 21) 6
22 4700I *20200004 BUSHING, VALVE GUIDE (BUNA) 6
23 4018-18 700030711 SCREW, VALVE GUIDE 12
24 4018-19 700048511 CAPSCREW, SUCTION MANIFOLD 24
25 568-442 99609442 GASKET, SUCTION MANIFOLD 3
26 8376-25MOD   MANIFOLD, DISCHARGE 1
27 2988 1290344 SEAL, DISCHARGE MANIFOLD 3
28 8590/6/1-   SUCTION MANIFOLD 1







"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump





Item Description Part Number Type of pump
1 Suction Manifold T270001037 T028500429 12T1600 mud pump
2 Crosshead T885001035-2 12T1600 mud pump
3 Crankshaft T840001054 12T1600 mud pump
4 Bull Gear T207001063 12T1600 mud pump
5 Pinion Shaft T348001061 12T1600 mud pump
6 Connecting Rods T237001057 12T1600 mud pump
7 Discharge Module T669201195 12T1600 mud pump
8 Suction Module T066920306 12T1600 mud pump
9 Connector, Discharge T007601020 12T1600 mud pump
10 Bushing, Discharge T000301034 12T1600 mud pump
11 Flange T474001057 12T1600 mud pump
12 Valve Cover T536001111- 12T1600 mud pump
13 End Plate T551001033 12T1600 mud pump
14 Seal T041003953 12T1600 mud pump
15 Wear Plate   12T1600 mud pump
16 10“-150# Blind Flange T940001090 12T1600 mud pump
17 Liner 7-1/2" 01917452 12T1600 mud pump
18 Liner 7" 01917450 12T1600 mud pump
19 Liner 6-3/4" 01917449 12T1600 mud pump
20 Liner 6-1/2" 01917448 12T1600 mud pump
21 Liner 6-1/4" 01917447 12T1600 mud pump
22 Liner 5-1/2" 01917446 12T1600 mud pump
23 Liner 5" 01917639 12T1600 mud pump
24 Pistons   12T1600 mud pump
25 Valves & Seats   12T1600 mud pump
26 Liner Gaskets   12T1600 mud pump





"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump





Item Description Part No.
  Complete Assembly 8490-2A
1 Threaded Flange 4475
2 Liner Wear Plate 8490-3
3 Module and Wear Plate Gasket 2988
4 Screw Gland 4575
5 Plug Assembly w/Guide & Bushing 4675-2A
6 Plug Seal P-129
7 Valve Guide 4775-2
8 Valve Guide Bushing 4700-I
9 Valve Guide Stud w/Nut 4016-99
10 Valve Cover Stud w/Nut 4015-2
11 Power End Stud w/Nut 4016-9
12 Liner Retainer Capscrew 4017-36
13 Liner Retainer Flange 6490-3
14 Liner Retainer Pilot Ring 8422-3
15 Liner Retainer Nut 6590-1
16 Suction Module Stud w/Nut 4016-97
17 Suction Module Studded 8490-2
18 Discharge Module Studded 8490-1
19 Dowel Pin 8488-5
20 Discharge Manifold Stud w/Nut 4017-46



"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump







ITEM # OEM PART # MISSION PART # DESCRIPTION QTY PER PUMP AVAILABLE
1   FEMPZ789CA ASSY, COMPLETE FLUID END MODULE (INCLUDES ITEMS 1-22) 3 OK
1A 200PZL029F FEMPZ789 MODULE, STUDDED FLUID END (INCLUDES ITEMS 1A-9) 3 OK
  205PZL029D       OK
1B   80721012 MODULE, STUDDED FLUID END MADE FROM 4135 MATERIAL (INCLUDES ITEMS 1B-9)   OK
2 79L188 PZ789LCS STUD, FRAME & LINER CLAMP 24 OK
3 50B36 6300200 NUT, FRAME & LINER CLAMP STUD 48 OK
4 79L73 PZ789GPFS STUD, FRAME 12 OK
5 50AQ30 PZ789PFSN NUT, FRAME STUD 12 OK
6 79AL6 PZ789TRS STUD, VALVE COVER 48 OK
7 50B34 PZ789TRSN NUT, VALVE COVER STUD 48 OK
8 202PZL110 PZ789DMS STUD, DISCHARGE MANIFOLD 12 OK
9 50B34 PZ789TRSN NUT, DISCHARGE MANIFOLD STUD 12 OK
10 2011861 PZ789EXPR RING, VALVE COVER GASKET EXPANDER 6 OK
11 2011862 7916749 GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6 OK
12 2007674 PZ789VGI BUSHING, VALVE GUIDE 6 OK
13 2011860 PZ789VC COVER, VALVE 6 OK
14 2011699 PZ789FLG RING, VALVE COVER THREADED (2 1/2" THICK) 6 OK
14A   PZ789HFLG RING, HEAVY VALVE COVER THREADED (3" THICK) 6 OK
15 2011857 PZ789CAP CAP, VALVE COVER LOCK 6 OK
16 2011701 PZ789PL PLATE, RETAINER 6 OK
17 2011700 PZ789LVG GUIDE, LOWER VALVE SUCTION 3 OK
18 95W2 PZLVGAWASHER WASHER, VALVE GUIDE LOCK 6 OK
19 655EE06S PZLVGABOLT SCREW 1/2"x1 3/4" 316SS HX HD C/S 6 OK
20 25AL35 7916747 GASKET, DISCHARGE MANIFOLD 3 OK
21 25G41 7923283 GASKET, SUCTION MANIFOLD 3 OK
22 1PV14 PZ789LC CLAMP, LINER 3 OK
23 2011706 PZ789LVGA ASSY., LOWER VALVE GUIDE (INCLUDES 12, 16 -19) 3 OK
24 75A74N 700044111 CAPSCREW, SUCTION MANIFOLD - NOT SHOWN 24 OK
25   7619066 WASHER, SUCTION MANIFOLD CAPSCREW LOCK 24 OK
    7924509 MODULE SEAL KIT: (KIT INCLUDES CYLINDER HEAD, VALVE COVER GASKET, LINER GASKET, DISCHARGE MANIFOLD GASKET, SUCTION MANIFOLD GASKET) 3 OK
Liners, Pistons and Valves
1 202PZL482A PZ7/8/9 FLUID VALVE ASSY   OK
2 202PZL039 PZ7/8/9 SEAT, THREE WEB   OK
3 2010512 PZ7/8/9 INSERT, VALVE   OK
4 201PZG456 PZ7 LINER 4-1/2"   OK
5 200PZG456 PZ7 LINER 5"   OK
6 PY13995 PZ7 LINER 5.5"   OK
7 PY13960 PZ7 LINER 6"   OK
8 PY13965 PZ7 LINER 6.5"   OK
9 PY13970 PZ7 LINER 7"   OK
10 206PZJ456 PZ8/9 LINER 4"   OK
11 205PZJ456 PZ8/9 LINER 4-1/2"   OK
12 204PZJ456 PZ8/9 LINER 5"   OK
13 203PZJ456 PZ8/9 LINER 5.5"   OK
14 202PZJ456 PZ8/9 LINER 6"   OK
15 201PZJ456 PZ8/9 LINER 6.5"   OK
16 2067PZJ456 PZ8/9 LINER 7"   OK

GARDNE DENVER PZ7/8/9 POWER END SPARES
1 66D13 PZ-7 MAGNETIC PLUG   OK
2 12W75 PZ-7 PINION BEARING (JACK SHAFT BEARING)   OK
3 12BA20 PZ-7 MAIN BEARING (ECCENTRIC)   OK
4 12BA18 PZ-7 BEARING, CONROD-ECCENTRIC   OK
5 74D18 PZ-7 RING RETAINER FOR CON ROD BEARING   OK
6 12BA19 PZ-7 BEARING ROLLER, CROSSHEAD PIN   OK
7 PZ838 PZ-7 PIN LOCK   OK
8 200PZG309 PZ-7 CROSSHEAD SLIDE   OK
9 200PZG005 PZ-7 CROSSHEAD   OK
10 200PZG189 PZ-7 PIN-CROSSHEAD   OK
11 202PZG168 PZ-7 PLATE RETAINER, CROSSHEAD PIN   OK
12 300PZG839 PZ-7 ROD EXTENSION   OK
13 300PZL362 PZ-7 SEAL HOUSING -OIL STOP HEAD   OK
14 301PZL362 PZ-7 SEAL HOUSING -OIL STOP HEAD   OK
15 20011872 PZ-7 SEAL OIL   OK
16 25BC69N PZ-7 GASKET   OK
17 SFXK840 PZ-7 BAFFLE   OK
18 40L17 PZ-7 GAUGE OIL LEVEL SIGHT   OK
19 27H11 PZ-7 GAUGE, OIL TEMPERATURE   OK
20 26C18 PZ-7 FILTER-OIL   OK
21 200PZG309 PZ-7 SLIDE-crosshead   OK
22 60DD39 PZ-7 SEAL, Oil   OK
23 200PZG309 PZ-7 PZ7 GUIDE, CROSSHEAD   OK
24 60DD39 PZ-7 PZ7 OIL SEAL   OK
25 200 PZG2555 PZ-7 ECCENTRIC   OK
26 200PZG280 PZ-7 GEAR-DRIVEN   OK
27 200PZG003 PZ-7 CONNECTING ROD   OK
28 200PZG069 PZ-7 MANIFOLD SUCTION   OK
29 200PZG071 PZ-7 MANIFOLD- DISCHARGE   OK
30 2012507 PZ-8 JACKSHAFT   OK
31 2009633 PZ-8 SEAL–OIL   OK
32 2012503 PZ-8 ECCENTRIC   OK
33 2012508 PZ-8 GEAR–DRIVEN   OK
34 2012506 PZ-8 CONNECTING ROD   OK
35 200PZH005 PZ-8 CROSSHEAD   OK
36 200PZH189 PZ-8 PIN–CROSSHEAD   OK
37 12W58 PZ-8 BEARING–ROLLER, Jackshaft   OK
38 12GF38 PZ-8 BEARING–ROLLER, Eccentric   OK
39 12W85 PZ-8 BEARING, Connecting Rod to Eccentric   OK
40 12BA44 PZ-8 BEARING–ROLLER, Crosshead Pin   OK
41 1PO183 PZ-8 ROD–EXTENSION   OK
42 2009634N PZ-8 GASKET, Oil Stop Head   OK
43 2012513 PZ-8 HEAD–OIL STOP   OK
44 1PZ371 PZ-9 JACKSHAFT   OK
45 60G242 PZ-9 SEAL–OIL   OK
46 2013705 PZ-9 ECCENTRIC   OK
47 1PZ180 PZ-9 GEAR–DRIVEN   OK
48 PZ417 PZ-9 CONNECTING ROD   OK
49 200PZJ005 PZ-9 CROSSHEAD   OK
50 PZ189 PZ-9 PIN–CROSSHEAD   OK
51 PZ183 PZ-9 ROD–EXTENSION   OK
52 1PZ226 PZ-9 HEAD–OIL STOP   OK
53 12W60 PZ-9 BEARING–ROLLER, Jackshaft   OK
54 12GF36 PZ-9 BEARING–ROLLER, Eccentric   OK
55 12W84 PZ-9 BEARING, Connecting Rod to Eccentric   OK
56 12AM3 PZ-9 BEARING–ROLLER, Crosshead Pin   OK







"L" MODULE FOR EMSCO FB-1600 mud pump, EMSCO FB1600 mud pump, National EMSCO mud pump liner, Drillmec Mud pump



GARDNER DENVER PZ-7, PZ-8, PZ-9 W/ WEAR PLATE FLUID END MODULE & ACCESSORIES

ITEM # OEM PART # MISSION PART # DESCRIPTION QTY PER PUMP
    FEMPZ789WPCA ASSY, COMPLETE FLUID END MODULE W/ WEAR PLATE & SEAL (INCLUDES ITEMS 1-25) 3
1   FEMPZ789WP MODULE, STUDDED FLUID END W/ WEAR PLATE GROOVE (INCLUDES ITEMS 1-25) 3
2 79L188 PZ789LCS STUD, FRAME & LINER CLAMP 24
3 50B36 6300200 NUT, FRAME & LINER CLAMP STUD 48
4 79L73 PZ789GPFS STUD, FRAME 12
5 50AQ30 PZ789PFSN NUT, FRAME STUD 12
6 79AL6 PZ789TRS STUD, VALVE COVER 48
7 50B34 PZ789TRSN NUT, VALVE COVER STUD 48
8 202PZL110 PZ789DMS STUD, DISCHARGE MANIFOLD 12
9 50B34 PZ789TRSN NUT, DISCHARGE MANIFOLD STUD 12
10 2011861 PZ789EXPR RING, VALVE COVER GASKET EXPANDER 6
11 2011862 7916749 GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) 6
12 2007674 PZ789VGI BUSHING, VALVE GUIDE 6
13 2011860 PZ789VC COVER, VALVE 6
14 2011699 PZ789FLG RING, VALVE COVER THREADED (2 1/2" THICK) 6
14A   PZ789HFLG RING, HEAVY VALVE COVER THREADED (3" THICK) 6
15 2011857 PZ789CAP CAP, VALVE COVER LOCK 6
16 2011701 PZ789PL PLATE, RETAINER 6
17 2011700 PZ789LVG GUIDE, LOWER VALVE SUCTION 3
18 95W2 PZLVGAWASHER WASHER, VALVE GUIDE LOCK 6
19 655EE06S PZLVGABOLT SCREW 1/2"x1 3/4" 316SS HX HD C/S 6
20 25AL35 7916747 GASKET, DISCHARGE MANIFOLD 3
21 25G41 7923283 GASKET, SUCTION MANIFOLD 3
22 1PV14 PZ789LC CLAMP, LINER 3
23   PZ910WPINTL PLATE, WEAR 3
24   20100019 SEAL, WEAR PLATE 3
25 2011706 PZ789LVGA ASSY., LOWER VALVE GUIDE (INCLUDES 12, 16 -19) 3
26 75A74N 700044111 CAPSCREW, SUCTION MANIFOLD - NOT SHOWN 24
27   7619066 WASHER, SUCTION MANIFOLD CAPSCREW LOCK 24
    7924509 MODULE SEAL KIT: (KIT INCLUDES CYLINDER HEAD, VALVE COVER GASKET, LINER GASKET, DISCHARGE MANIFOLD GASKET, SUCTION MANIFOLD GASKET) 3





Contact Details
Qingdao National Premium Oilwell Machinery Co.,Ltd

Contact Person: Mr. Eric

Tel: 0086-15376875239

Send your inquiry directly to us (0 / 3000)

About Us
Weatherford Mud Pumps
National Mud Pumps
Mud Pump Chrome Liner
Contact Us
Mobile Site
Privacy Policy | China Southwest Pump Parts Supplier. Copyright © 2019 - 2024 premiummudpump.com. All Rights Reserved. Developed by ECER
