TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER

Certification
Good quality Mud Pump Zirconia Liners for sales
I'm Online Chat Now

TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER

China TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier
TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER supplier

Large Image :  TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER

Product Details:

Place of Origin: China, USA
Brand Name: DRILLMEC, SOUTHWEST, NATIONAL OILWELL, GARDNER DENVER
Certification: API
Model Number: 12T1600

Payment & Shipping Terms:

Minimum Order Quantity: 1 PIECE
Price: 1 TO 1000 USD
Packaging Details: Suitable to shipment by sea and air
Delivery Time: Some in stock
Payment Terms: L/C, T/T
Supply Ability: 3000 pieces per month
Detailed Product Description
Usage: Oil,Water,drill Rig Power: Electric,Hydraulic,diesel
Pressure: High Pressure,Low Pressure Application: Mining,oil
Structure: Piston Pump Fuel: Diesel,Electric
Theory: Centrifugal Pump Type: Mud Pump
Weight: 100-3700kg Color: Red And So On,Green Or Per Customer Design
Material: Cast Iron/stainless Steel Mud Suction Pump,Chrome Alloy Warranty: 12 Months
Feature: Mud Suction Pump Product Name: Mud Pump
Head: 10m Mud Suction Pump Oem: Can Be Accept,Applicable
Condition: New

        Premium can make and supply Hy-Chrome liners and Zicornia/Ceramic Liners for Emsco, Brewster, National Oilwell, Ideco, Gardner Denver, Weatherford, Drillmec, Bomco, Honghua, RG, Rongsheng, TSC, LS NOV, POT, Bentec, Wirth, Southwest, Ewco, Lewco, Baker Forum, Mud King, OPI, Texma, Haihua Group and more. We also have extensive knowledge of older and obsolete mud pumps and their parts. Our reach extends to customers around the world.





Texma DRILLMEC  12T1600 mud pump liner part number:





Drillmec 12T1600 TM11214284 TM11214285

TM11214286/

TM112009958

TM11214287/

TM112009959

TM11204288/

TM112009960

TM11204289/

TM112009961

TM11204290/

TM112009962





OEM Part Number for some popular brand mud pumps:



Mud Pump Models



Liner Inch

4” 4-1/2” 5” 5-1/2” 6” 6-1/2” 7”
Continental Emsco F-800 / 1000 / 05495450 PREM 05495500 PREM 05495550 PREM 05495600 PREM 05495650 PREM 05495700 PREM
Continental Emsco FB-1300 / 1600 05499400 PREM 05499450 PREM 05499500 PREM 05499550 PREM 05499600 PREM 05499650 PREM 05499700 PREM
Continental Emsco FC-2200 / / 05551500 PREM 05551550 PREM 05551600 PREM 05551650 PREM 05551700 PREM
Gardner Denver PAH-275

PA I3940

05519400 PREM

PA 13945

05445450 PREM

PA 13950

05445500 PREM

/ / / /
Gardner Denver PZ-7 PY13940 PY13945

PY13950

05493087 PREM

PY13955

05493085 PREM

PY13960

05493083 PREM

PY13965

05493081PREM

PY13970

05493079 PREM

Gardner Denver PZ-8/9

206PZJ456

05493400 PREM

205PZJ456

05493450 PREM

204PZJ456

05493500 PREM

203PZJ456

05493550 PREM

202PZJ456

05493600 PREM

200PZJ456

05493650 PREM

207PZJ456

05493700 PREM

Gardner Denver PZ-10/11

206PZL456

05496400 PREM

205PZL456

05496450 PREM

204PZL456

05496500 PREM

203PZL456

05496550 PREM

202PZL456

05496600 PREM

201PZL456

05496650 PREM

200PZL456

05496700 PREM

Gardner Denver PZL

206PZL456

05496400 PREM

205PZL456

05496450 PREM

204PZL456

05496500 PREM

203PZL456

05496550 PREM

202PZL456

05496600 PREM

201PZL456

05496650 PREM

200PZL456

05496700 PREM

Gardner Denver PZL-B-7500 PSI / / 05561500HP 05561550HP 05561600HP 05561650HP 05561700HP
Gardner Denver PZL W/SWFE 7500 PSI 05465400HP 05465450HP 05465500HP 05465550HP 05465600HP 05465650HP 05465700HP
Gardner Denver PX-11 7500 PSI / / 05561500HP 05561550HP 05561600HP 05561650HP 05561700HP
Ideco T-500 / 05512450 PREM 05512500 PREM 05512550 PREM 05512600 PREM 05512650 PREM 05512700 PREM
Ideco T-800 / 1000 05502400 PREM 05502450 PREM 05502500 PREM 05502550 PREM 05502600 PREM 05502650 PREM 05502700 PREM
Ideco T-1300 / 1600 / 05507450 PREM 05507500 PREM 05507550 PREM 05507600 PREM 05507650 PREM 05507700 PREM
National 7P-50 05466040 PREM 05466045 PREM 05466050 PREM 05466055 PREM 05466060 PREM / /
National 8-P-80 05464400 PREM 05464450 PREM 05464500 PREM 05464550 PREM 05464600 PREM 05464650 PREM /
National 9-P-100 / 10-P-130 05465400 PREM 05465450 PREM 05465500 PREM 05465550 PREM 05465600 PREM 05465650 PREM /
National 12-P-160 05466400 PREM 05466450 PREM 05466500 PREM 05466550 PREM 05466600 PREM 05466650 PREM 05466700 PREM
National 14-P-220 05545400 PREM 05545450 PREM 05545500 PREM 05545550 PREM 05545600 PREM 05545650 PREM 05545700 PREM
National JWS-165/340 05531400 PREM 05531450 PREM / / / / /
National JWS-400 05524400 PREM 05524450 PREM 05524500 PREM 05524550 PREM 05524600 PREM / /
Oilwell HD-1700-PT / / 05326500 PREM 05326550 PREM 05326600 PREM 05326650 PREM 05326700 PREM
Oilwell A-600-PT 05329400 PREM 05329450 PREM 05329500 PREM 05329550 PREM 05329600 PREM 05329650 PREM 05329700 PREM
Oilwell A-850-PT / A-1100-PT 05330400 PREM 05330450 PREM 05330500 PREM 05330550 PREM 05330600 PREM 05330650 PREM 05330700 PREM
Oilwell A-1400-PT / A-1700-PT 05326400 PREM 05326450 PREM 05326500 PREM 05326550 PREM 05326600 PREM 05326650 PREM 05326700 PREM



TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER



Item Description Part Nmber
1 VALVE API 8" FULL-OPEN VALVE 40392143
2 SEAT API 8"FULL-OPEN VALVE 40392144
3 SPRING API 8"FULL-OPEN VALVE 40392145
4 7"BI-METAL LINER 01919525
5 7" LINER GASKET 10913315
6 7"PISTON 01912155
7 6 1/2"BI-METAL LINER 01919511
8 6 1/2"LINER GASKET 01913581
9 6 1/2"PISTON 01912149
10 6"BI-METAL LINER 01919524
11 6" LINER GASKET 01913292
12 6"PISTON 01912163
13 5 1/2"BI-METAL LINER 01919523
14 5 1/2" LINER GASKET 01913508
15 5 1/2" PISTON 01912154
16 5"BI-METAL LINER 01919522
17 5"LINER GASKET 01913284
18 5"PISTON 01912153





 TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER



All our fluid end parts are manufactured to API 7K quality standards.



Parts are available for these popular pump models:



BOMCO/Emsco Mud Pumps:F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,

LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600
Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,
National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,
Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,

Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT



Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200

Russian Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32



WEATHERFORD/Ellis Williams: E-447, E-2200



Drillmec: 9T1000, 12T1600, 7TS600, 7TS500, 9T800



Romania: 3PN-1000, 3PN-1600, 3PN-2000



And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.



TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINERTEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINERTEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER



1,Plunger Size 3.38” - 4.00” Valve Part No. P107185 Seat Part No. P107802
Insert Part No. P107186 Spring
2,Plunger Size 4.50” Valve Part No. P107181 Seat Part No. P107180
Insert Part No. P107182 Spring
3,Plunger Size 5.00” - 6.00” Valve Part No. P107188 Seat Part No. P107187
Insert Part No. P107189 Spring4P102382
SPM2000
1,Plunger Size 3.75" Plunge Part No 3P103887
2,Plunger Size 4.00" Plunge Part No 3P100339
3,Plunger Size 4.50" Plunge Part No 3P100654
4,Plunger Size" 5.00" Plunge Part No 3P100233
5,Plunger Size" 5.50 Plunge Part No 3P107060
6,Plunger Size" 5.75" Plunge Part No 3P107061
7,Plunger Size 6.00 Plunge Part No 3P107062
SPM
TWS 250 Plunger Size 1.75"-3" 3.25"-4"
TWS 400 Plunger Size 2 .50"-3" 3 .50"-4 .50”
TWS 500LW-600 Plunger Size 2 .75" 3"-4 .75"
TWS 600S Plunger Size 2 .50"-3" 3.50"-4 .50"
TWS 900 Plunger Size 3.50"-4"
TWS 1250LW Plunger Size 4"
OPI880 Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0”
TWS1000LW,TWS1300
Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0” 6.5 “ 6.75”
TWS1600 Plunger Size 3.5” 3.75” 4.0” 4.50” 5.0” 5.5” 5.75 “6.0”
TWS1800 Plunger Size 3.5” 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0”
TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
5.50” 5.75” 6.0”
TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5



TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER



Brewster ® Mud Pumps B-550 • B-750 • B-1000 • 1100T • B-1300
Continental Emsco ® Mud Pumps F-350 • F-500 • F-650 • F-800 • F-1000 • FA-1300 • FB-1600 FB1600
Gaso ® Mud Pump 1563 • 1740-55 • 1844-60 • 2010-50 • 2200-49 • 2651 • 2652
Gardner Denver ® Mud Pumps
PAH • PZ-7 PZG • PZ-8 PZH • PZ-9 PZJ • PZ-10 PZK • PZ-11 PZL
Gardner Denver ® Well Service TEE • PE-5 • PA-8 • PAH • PJ-8 • TGF-225
Gardner Denver ® Continuous Duty GD-55T • GD-60T • GD-100T • GD-125T • GD-150T • GD-180T • GD-200T
Ideco ® Mud Pumps MM-200 • MM-300 • MM-500 • MM-500F • MM-550
Ideco ® Mud Pumps MM-550F • MM-700 • MM-700F • T-500
Ideco ® Mud Pumps T-500 • T-800 • T-1000 • T-1300 • T-1600
National ® J Series Mud Pumps J-30 • J-60 • J-100 • J-165 • J-275 • J-375 • J-625 • JWS-340 • JWS-400
National ® Mud Pumps K-280 • K-380 • K-500 • K-500A • K-700A
National ® P Series Mud Pumps 7P-50 • 8P-80 • 9P-100 • 10P-130 • 12-P-160 / 12P-160 / 12P160
Oilwell ® Mud Pumps A-350-PT • 560-PT • A-560-PT • 850-PT • A-850-PT • 1100-PT
Oilwell ® Mud Pumps A-1100-PT • 1400-PT • A-1400-PT • 1700-PT • A-1700-PT / A1700-PT
Oilwell ® Plunger Pumps C-323 through B-558 • SA-640-50 through SB-644-B
OPI ® Mud Pumps 350-D • 00-DL • 700-HDL • 1000-HDL
Wheatley ® Mud Pumps 1036 • 6070 • 7024 • 7036
Fluid End Modules
National® - Oilwell® - Continental Emsco® - Gardner Denver® - Ideco® - Skytop Brewster®
Pulsation Dampener
Hydril Type "K" Pulsation Dampener
Popular Mud Pump Spare Parts



TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER





Parts are available for these popular pump models:

BOMCO/Emsco Mud Pumps:F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,

LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600

Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,

National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,

Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,

Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT



Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200



Russian Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32



WEATHERFORD/Ellis Williams: MP-5, MP-8, MP-10, MP-13, MP-16, E-447, E-2200, E1600



Drillmec: 9T1000, 12T1600, 7TS600, 7TS500, 9T800,14T2200



Romania: 3PN-1000, 3PN-1600, 3PN-2000



And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.



TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER





FLUID END TYPE MODEL OF PUMP SIZE OF PUMP
SOUTHWEST 7500 P.S.I. BOMCO F-1600 7 ½” X 12”

TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER

ITEM NO.



PART NO.



DESCRIPTION

QTY. REQ’D
  8404-25A FLUID END ASSEMBLY: (CONSISTS OF ITEMS: 3,4,17,18,19,20,21,22,23,24,25,26,27,28,29,30,31,34,35,36,38,39,41,42)
1 1376YXX LINER REFER TO GUIDE FOR ORDERING CHART ON PG. 6 FOR TYPE (G); (Y); AND FOR BORE SIZE (XX) 3
2 2930-XX LINER SEAL (ALSO AVAILABLE IN URETHANE PART# 2930-XXU) 3
3 8490-28 LINER WEARPLATE (WITH 568-443 O-RING) 3
4 2988 WEARPLATE AND MODULE SEAL (ALSO AVAILABLE IN URETHANE PART# 2988U) 6
5 XX-BYY PISTON REFER TO GUIDE FOR ORDERING CHART ON PG. 6 FOR SIZE (XX) AND FOR TYPE (YY) 3
6 568-225 PISTON SEAL 3
7 6278-25 PISTON ROD (WITH ELASTIC STOP NUT) 3
8 API-4ESN PISTON ROD NUT 3
9 1290-2 PISTON ROD CONNECTING STUD 3
10 6284-1 SUB ROD 3
11 6274CWY ROD CLAMP (WITH WATER JACKET) 3
11A 1200H30 HOSE (1/2” X 30” WITH 1/2” MALE X 3/8” MALE CONNECTIONS) 3
11B 1286CWYFP ROD CLAMP WATER SPRAY MANIFOLD WITH PIPE 3
11C 4020-29 BOLT (7/8-9 GRADE 8 BOLT WITH LOCK NUT AND WASHER) 6
12 1200G74 PONY ROD 3
13 SEE PAGE VALVE 6
14 SEE PAGE VALVE INSERT 6
15 SEE PAGE VALVE SPRING 6
16 SEE PAGE VALVE SEAT 6
  SWTM1700 HYDRAULIC SEAT PULLER KIT COMPLETE (REFER TO TOOLS SECTION IN CATALOG) 1
17 4488-25 VALVE COVER FLANGE 6
18 4588-25 SCREW GLAND 6
19 4690-25A PLUG (COMPLETE WITH VALVE GUIDE; BUSHING; AND SCREWS) INCLUDES ITEMS 20, 21, 22, &23 6
20 P115 HP VALVE COVER PLUG NITRILE SEAL (ALSO AVAILABLE IN URETHANE PART # P115U) 6
21 4788-25R VALVE GUIDE (COMPLETE WITH BUSHING #4700I) 6
22 4700I VALVE GUIDE INSERT (ALSO AVAILABLE IN URETHANE PART # 4700IU) 6
23 4018-18 VALVE GUIDE SCREW 12
24 4015-2 VALVE COVER STUD (WITH SW PART# HHN1250-7 1 1/4"-7 HEAVY HEX NUT) 72



FLUID END TYPE MODEL OF PUMP SIZE OF PUMP
SOUTHWEST 7500 P.S.I. BOMCO F-1600 7 ½” X 12”

TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER

ITEM NO.



PART NO.



DESCRIPTION

QTY. REQ’D
25 4017-33 POWER END STUD (WITH SW PART# HHN1500-8 1 1/2"-8 HEAVY HEX NUT) 30
26 568-443 WEARPLATE 'O' RING 3
27 6490-25 LINER RETAINER FLANGE 3
28 4019-51 LINER RETAINER CAPSCREW 36
29 6590-25 LINER RETAINER NUT 3
30 4019-61 SUCTION MODULE STUD (WITH SW PART# HHN1750-8 1 3/4"-8 HEAVY HEX NUT) 18
31 4018-19 SUCTION MANIFOLD CAPSCREW 18
32 8590-6 SUCTION MANIFOLD 1
33 568-442 SUCTION MANIFOLD 'O' RING 3
34 8404-26 SUCTION MODULE 3
35 8404-27 DISCHARGE MODULE 3
36 8488-5 DOWEL PIN 6
37 8376-25MOD DISCHARGE MANIFOLD 1
38 4019-60 DISCHARGE MANIFOLD STUD (WITH SW PART# HHN1250-7 1 1/4"-7 HEAVY HEX NUT) 18
39 2988 DISCHARGE MANIFOLD SEAL 3
40 6490-25P LINER RETAINER PULLER 1
41 LW875 LOCKWASHER 7/8 18
42 LW500 LOCKWASHER ½ 12

  8590-6BFA

BLIND FLANGE IS AVAILABLE FOR CAPPING UNUSED FLANGES ON 8590-6 SUCTION MANIFOLD –

(8590-6BFA INCLUDES 8590-6BF BLIND FLANGE AND 568-456 O-RING) SEE SEPARATE PG. FOR DETAILS








SOUTHWEST 7500 P.S.I. BOMCO F-1600 GUIDE TO ORDERING
PISTONS LINERS LINER SEALS
SIZE FAIL-SAFE DUAL-DURO® BLACK CAT GRAYLOY® ZIRCONIA RUBBER URETHANE
4" 76BFS 76BDD 76BBC 1376G06   2930-06 2930-06U
4 1/4" 77BFS 77BDD 77BBC 1376G07   2930-07 2930-07U
4 1/2" 78BFS 78BDD 78BBC 1376G08 1376ZIR08 2930-08 2930-08U
4 3/4" 79BFS 79BDD 79BBC 1376G09 1376ZIR09 2930-09 2930-09U
5" 81BFS 81BDD 81BBC 1376G1 1376ZIR1 2930-1 2930-1U
5 1/4" 82BFS 82BDD 82BBC 1376G2   2930-2 2930-2U
5 1/2" 83BFS 83BDD 83BBC 1376G3 1376ZIR3 2930-3 2930-3U
5 3/4" 84BFS 84BDD 84BBC 1376G4 1376ZIR4 2930-4 2930-4U
6" 85BFS 85BDD 85BBC 1376G5 1376ZIR5 2930-5 2930-5U
6 1/4" 86BFS 86BDD 86BBC 1376G6 1376ZIR6 2930-6 2930-6U
6 1/2" 87BFS 87BDD 87BBC 1376G7 1376ZIR7 2930-7 2930-7U
6 3/4" 88BFS 88BDD 88BBC 1376G8   2930-8 2930-8U
7" 89BFS 89BDD 89BBC 1376G9 1376ZIR9 2930-9 2930-9U
7 1/4" 91BFS 91BDD 91BBC 1376G10 1376ZIR10 2974-11 2974-11U
7 1/2" 92BFS 92BDD 92BBC 1376G11   2974-11 2974-11U



TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER

SOUTHWEST 8482-A FLUID END

FOR NATIONAL 14-P-220

FLUID END TYPE MODEL OF PUMP SIZE OF PUMP
SOUTHWEST 7500 P.S.I. NATIONAL 14-P-220 9” X 14”





ITEM P/N DESCRIPTION QTY. REQ’D
  8482-A FLUID END ASSEMBLY: (CONSISTS OF ITEMS 3, 4, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 32, 33, 34)
1 6382G-XX LINER (REFER TO GUIDE FOR ORDERING CHART FOR TYPE (G); (Y); AND FOR BORE SIZE (XX)) 3
2 2930-XX LINER SEAL 3
3 8482-4 WEARPLATE 3
4 2930-09 WEARPLATE & MODULE SEAL 6
5 XX-BYY PISTON (REFER TO GUIDE FOR ORDERING CHART FOR SIZE (XX) AND FOR TYPE (YY)) 3
6 568-225 PISTON O-RING 3
7 6282W32 PISTON ROD (W/ ELASTIC STOP NUT) 3
8 API-4ESN PISTON ROD ELASTIC STOP NUT 3
9 6282-1 SUB ROD 3
10 6282CWY ROD CLAMP (CONSIST OF 10A, 10B, 10C) (FOR CLAMP ONLY USE 6282C) 6
10A 1200H30 HOSE (1/2” X 30” WITH ½” MALE X 3/8” MALE CONNECTIONS) 6
10B 1200160 PIPE (3/8” X 16” GALVANIZED AND THREADED ON ONE END) 6
10C 4019-77 ROD CLAMP BOLT (3/4-10 GRADE 8 BOLT WITH LOCK NUT AND WASHER) 12
11 6200G82 PONY ROD 3
12   VALVE 6
13   VALVE INSERT (IF REQUIRED) 6
14   VALVE SPRING 6
15   VALVE SEAT 6
  SWTM1700 HYDRAULIC SEAT PULLER KIT COMPLETE (REFER TO TOOLS SECTION IN CATALOG) 1
16 4482 THREADED FLANGE 6
17 4582 SCREW GLAND 6
18 4682A PLUG (COMPLETE WITH VALVE GUIDE, BUSHING, AND SCREWS, AND BUSHING) 6
19 P113 HP VALVE COVER PLUG NITRILE SEAL 6
20 4782R VALVE GUIDE (COMPLETE W/ BUSHING #4700I) 6
21 4700I VALVE GUIDE INSERT (ALSO AVAILABLE IN URETHANE PART# 4700IU) 6
22 4019-75 VALVE GUIDE SCREW 24
23 4015-54 VALVE COVER STUD (WITH SW PART# HHN1500-6 1 ½-6 HEAVY HEX NUT) 84
24 4019-24 POWER END STUD (WITH SW PART# HHN1500-6 1 1/2-6 HEAVY HEX NUT) 30
25 6482 LINER RETAINER FLANGE 3
26 4015-52 LINER RETAINER STUD (WITH SW PART# HHN1250-7 1 ¼-7 HEAVY HEX NUT) 18
27 6582 LINER RETAINER NUT 3
28 4019-74 SUCTION MODULE STUD (WITH SW PART# HHN2000-8 2-8 HEAVY HEX NUT) 18
29 4018-19 SUCTION MANIFOLD CAP SCREW 24
30 8582 SUCTION MANIFOLD 1
31 AJO326 SUCTION MANIFOLD SEAL 3
32 8482-2S SUCTION MODULE 3
33 8482-1D DISCHARGE MODULE 3
34 8488-5 DOWEL PIN 6
35 2982-3 DISCHARGE END ADAPTER SEAL 2
36 4017-4 DISCHARGE END ADAPTER CAP SCREW 24
37 BX169 RING JOINT 2
38 4020-21 BLIND FLANGE STUDS (WITH SW PART# HHN1125-7 1-1/8”-7 HEAVY HEX NUTS) 24
39 2982-2 DISCHARGE CONNECTOR SEAL 4
40 8382-1 DISCHARGE CONNECTOR 2
41 8382-3 DISCHARGE CONNECTOR BACK-UP RING 2
42 4018-18 DISCHARGE CONNECTOR CAPSCREW 16
43 2982-1 DISCHARGE CONNECTOR END SEAL 2
44 8382-2 DISCHARGE CONNECTOR ADAPTER 2







TEXMA DRILLMEC 12T1600 Mud Pump Liners, 14T-2200 ceramic liner, 9T-1000 ZIRCONIA LINER, NATIONAL 14P-220 MUD PUMP LINER



Brewster ® Mud Pumps B-550 • B-750 • B-1000 • 1100T • B-1300

Continental Emsco ® Mud Pumps F-350 • F-500 • F-650 • F-800 • F-1000 • FA-1300 • FB-1600 FB1600

Gaso ® Mud Pump 1563 • 1740-55 • 1844-60 • 2010-50 • 2200-49 • 2651 • 2652

Gardner Denver ® Mud Pumps

PAH • PZ-7 PZG • PZ-8 PZH • PZ-9 PZJ • PZ-10 PZK • PZ-11 PZL

Gardner Denver ® Well Service TEE • PE-5 • PA-8 • PAH • PJ-8 • TGF-225

Gardner Denver ® Continuous Duty GD-55T • GD-60T • GD-100T • GD-125T • GD-150T • GD-180T • GD-200T

Ideco ® Mud Pumps MM-200 • MM-300 • MM-500 • MM-500F • MM-550

Ideco ® Mud Pumps MM-550F • MM-700 • MM-700F • T-500

Ideco ® Mud Pumps T-500 • T-800 • T-1000 • T-1300 • T-1600

National ® J Series Mud Pumps J-30 • J-60 • J-100 • J-165 • J-275 • J-375 • J-625 • JWS-340 • JWS-400

National ® Mud Pumps K-280 • K-380 • K-500 • K-500A • K-700A

National ® P Series Mud Pumps 7P-50 • 8P-80 • 9P-100 • 10P-130 • 12-P-160 / 12P-160 / 12P160

Oilwell ® Mud Pumps A-350-PT • 560-PT • A-560-PT • 850-PT • A-850-PT • 1100-PT

Oilwell ® Mud Pumps A-1100-PT • 1400-PT • A-1400-PT • 1700-PT • A-1700-PT / A1700-PT

Oilwell ® Plunger Pumps C-323 through B-558 • SA-640-50 through SB-644-B

OPI ® Mud Pumps 350-D • 00-DL • 700-HDL • 1000-HDL

Wheatley ® Mud Pumps 1036 • 6070 • 7024 • 7036

Fluid End Modules

National® - Oilwell® - Continental Emsco® - Gardner Denver® - Ideco® - Skytop Brewster®

Pulsation Dampener

Hydril Type "K" Pulsation Dampener

Popular Mud Pump Spare Parts





Mud Pump Manufactures and Models include:

Brewster Mud Pumps

B-550 | B-750 | B-1000 | 1100T | B-1300

Continental Emsco Mud Pumps

FF-FXF | FG-FXG (A thrugh L) | FD-FXX | FC-FXX | FD-FXD | FC-FXD | FY-FXD

Continental Emsco Mud Pumps

GP-GXP | GR-GXP | GP-GXR | GR-GXR |PA-8 | PAH

Continental Emsco Mud Pumps

PJ8 | PZ-7 | PZ-8 | PZ-9 | PZ-10 | PZ-11 | PXL

Ellis Williams (Luko) Mud Pumps

WW-440 | 14W-400 | 15W-600 | 9W-1000

Gaso Mud Pump

1563 | 1740-55 | 1844-60 | 2010-50 | 2200-49 | 2651 | 2652

Gardner Denver Mud Pumps

FF-FXF;FG-FXG;A thru L FD-FXX FC-FXX FD-FXD FC-FXD FY-FXD GP-GXP GR-GXP GP-GXR GR-GXR PA-8 PJ8 PZ-7 PZ-8 PZ-9 PZ-10 PZ-11 PXL



Ideco Mud Pumps

MM-200 | MM-300 | MM-500 | MM-500F | MM-550

Ideco Mud Pumps

MM-550F | MM-700 | MM-700F | T-500

Ideco Mud Pumps

T-800 | T-1000 | T-1300 | T-1600

National Mud Pumps

C-150 | C-250 | C-350 | E-500 | E-700 | G-700 | G-1000



National Mud Pumps

K-280 | K-380 | K-500 | K-500A | K-700A



National Mud Pumps

7P-50 | 8P-80 | 9P-100 | 10P-130 | 12P-160



Oilwell Mud Pumps

6P-HD | 610-P | 212-P | 214-P | 218-P



Oilwell Mud Pumps

350-PT | 560-PT | A-560-PT | 850-PT | A-850-PT | 1100-PT



Oilwell Mud Pumps

A-1100-PT | 1400-PT | A-1400-PT | 1700-PT | A-1700-PT



OPI Mud Pumps

350-D | 700-HDL | 1000-HDL



Wheatley Mud Pumps

1036 | 6070 | 7024 | 7036



Wilson Mud Pumps

600 | 900





Contact Details
Qingdao National Premium Oilwell Machinery Co.,Ltd

Contact Person: Mr. Eric

Tel: 0086-15376875239

Send your inquiry directly to us (0 / 3000)
